Chapter 3 Installation & Initial Set Up
orientation. Check for correct orientation of the alignment key ways, then make
connections as shown in Fig. 3.6.
3) Screw the outer casing of the plug clockwise until the connector is fully fastened.
Fig. 3.6 Connecting the Power Cable to the PSU
Fig. 3.7 Connector Identification
OUTPUT
±15V DC 3.0A/0.1A, 1.4/6.3 msec
OUTPUT
±15V DC 3.0A/0.1A, 1.4/6.3 msec
J9
J6
J10
J7
JP4
JP7
