THORLABS HDR50 - Page 11

Rev B Dec 2019
Page 9
Chapter 5 Specification and Dimensions
5.2 Dimensions
Fig. 5.1 HDR50(/M) Dimensions
SM2 THREAD (2.035 - 40)
0.27 in [6.9 mm] DEEP
ON ROTATING TABLE
8-32 [M4] 0.27 in [6.9 mm] DEEP
4 PLACES EQUALLY SPACED
2.27 in
57.8 mm
2.32in
59.0mm
1.48 in
37.5 mm
1.47 in
37.3 mm
0.16 in 4.0 mm X 0.18 in 4.5 mm
x 0.16 in [4.0 mm] DEEP DOWEL SLOT
TO LOCATE ACCESSORIES
0.3 in [7.5 mm] TO TAKE
1/4 in [M6] SOCKET CAP SCREWS
4 PLACES
0.16 in [4mm] x 0.16 in [4mm]
DEEP DOWEL HOLE
TO LOCATE ACCESSORIES
7.46 in
189.4 mm
0.97 in
25.0 mm
2.00 in
50.0 mm
1/4 "- 20 [M6]
0.14 in [3.5 mm] DEEP
4 PLACES
1.73 in
44.0 mm
1.52 in
38.7 mm
0.80 in
20.3 mm
0.97 in
24.6 mm
2.00 in
50.0 mm
