The Spartacus mono power amplifier is the world's finest audio amplifier and an
absolutely unique component. Its unusual topology, premium parts, and flexibility make it
a pleasure to hear and operate. Spartacus is two stage shunt regulated Directly Heated
Triode power amplifier.
Features
2 inputs – one unbalanced on RCA and one balanced on XLR
Amplification level switch – low, medium and high
Speaker impedance switch - 4 Ohm / 8 Ohm
Inside you get
Tube rectified choke input PSU feeding film reservoir capacitors. Then each stage has it’s
own constant current fed shunt regulator.
The input/driver stage is a single ended directly heated triode with grounded cathode
and fixed bias and loaded with a rather special Japanese transformer.
The output stage is a pair of directly heated triodes operating independent windings on
the same Japanese Permalloy core transformer biased trough innovative servo circuitry.
The heating of all the filaments is done trough voltage controlled current sources.
The case is made of plates of different thickness machined solid aircraft grade aluminium.
INTRODUCTION
4
• Inputs
- 1 unbalanced RCA connector
- 1 balanced XLR connector
• Output ……………….................................................….. up to 70W in 4 Ω or 8 Ω
• Power supply ……………….....................................................…….. 115 or 230 V
• Power consumption …………….......................................................…….. 380W
• Dimensions ………………....................................…….. 210W x 440D x 420H mm
• Weight ………………............................................................................…….. 35Kg
• Finish ……..........................................…….. Black or Silver anodized aluminum
• Tube compliment :
- 1x PX 25 amplification
- 2x EML520B-V3 amplification
- Г- 811 shunt regulator
- СГ-13П voltage reference
· 2 х 6Д22С rectifier
SPECIFICATION
