Thrax Spartacus - 5 Top Panel; 6 Front Panel

Amplification level switch
– low, medium and high positions to match to the preamplifier output.
Output impedance switch
- 4 Ohm / 8 Ohm to match the loudspeaker impedance.
TOP PANEL
"ON/OFF" Button
Switches the unit on and off. See OPERATION SECTION for details.
EML 520B V3
ON/OFF
Button
Status LED
6Д22С
EML 520B V3
6Д22С
Г811
PX25
Output Impendance
4/8
СГ13
Gain
FRONT PANEL
7
