step 10: install the door handles and hinges
10.1. Extend two hinges (H12) and rest the hinge cups onto the cutouts of each door (H and I).
10.2. Fasten the hinges into place using the 15 mm screws (H13). Tighten them with a Phillips screwdriver.
10.3 Orient and attach one handle (H14) to the front of each door (H and I) with two 18 mm handle bolts (H15).
(H14) x 4
handle
H12
H12
H12
H13
H13
H13
H13
H14
H14
H15 H15
H
I
x3
NOTE: DO NOT use power tools.
H12
(H12) x 8
door hinge
(H13) x 16
M4 x 15 mm screw
(Nickel)
(H15) x 8
M4 x 18 mm handle bolt
