step 11: attach the doors
11.1. Ask for assistance to lift the assembled unit upright and position it near the final location.
11.2. Pick up the middle left door (I) and attach the extended hinge bases to the left side of the partition panel (E) with eight nickel screws (13), using the pilot
holes as a guide. Make sure that both door hinges engage and function properly.
11.3. Repeat the same process to attach the other doors (H) into place.
11.4. Open and close the doors to make sure they are aligned and shut correctly. If necessary, adjust the screws for a good fit. Refer to the hinge sticker on door
for adjustment.
H13
H12
D
D
E
H
H
I
H
D
E
H
I
CAUTION: Heavy! You may
need assistance with this step.
(H13) x 32
M4 x 15 mm screw
(Nickel)
