step 12: install the adjustable shelves and put cam lock covers
(H9) x 8
shelf support
(H16) x 10
cam lock cover
12.1. Open the doors and insert four shelf supports (H9) in the holes at the desired height inside each compartment. Make sure you place the four shelf supports
at the same level to level the shelf. Tilt and rest the adjustable shelves (G) onto the shelf supports.
12.2. Plug the cam lock covers (H16) onto the visible cam locks to conceal the cams.
