step 9: attach the base
9.1. Insert twelve 15 mm bolts (H4) with the lock washers (H5) and flat washers (H6) through the metal tabs on the assembled base and securely screw into the
bottom panel (B).
9.2. Set the floor levelers to the correct height.
(H5) x 12
lock washer
(H6) x 12
flat washer
H4
H5
H6
B
J
J
K
K
B
J
(H18) x 1
hex wrench
(H4) x 12
1/4” x 15 mm bolt
15
