step 8: fasten the back panel
(H7) x 24
M3.5 x 15 mm
washer head screw
H7
C
C
The adhesive tape faces outward.
8.1. Now, go back and tighten all Cam Locks and Screws. Make sure that all the parts are tight and there are no gaps between the pieces. This will help keep the
unit square.
8.2. Ask for assistance to flip around the previous assembly at its front edges.
8.3. Unfold the Back Panel (C) and lay it to the back edges of the assembled unit. Make sure that the overlaps on the panels are even all the way around. Attach
the Back Panel (C) in place with the 15 mm Washer Head Screws (H7) provided.
NOTE: We recommend attaching the back panel with screws at the corner first.
D
CAUTION: Heavy! You may
need assistance with this step.
14
