Threshold STUDIO MCGEE Marvale TGAVC68-21 - Page 3

hardware
(H1) x 10
cam lock
(H2) x 10
cam bolt
(H3) x 12
M8 x 30 mm
wood dowel
(H4) x 16
1/4” x 15 mm bolt
(H6) x 16
flat washer
(H8) x 6
M4 x 38 mm screw
(H12) x 8
door hinge
(H10) x 2
door stopper
(H11) x 4
M3 x 10 mm screw
(H15) x 8
M4 x 18 mm handle bolt
(H9) x 8
shelf support
(H13) x 48
M4 x 15 mm screw
(Nickel)
(H7) x 24
M3.5 x 15 mm
washer head screw
(H5) x 16
lock washer
(H14) x 4
handle
3
