1.1. Orient and attach two bottom stretchers (K) to one leg assembly (J) with two 15 mm bolts (H4), two lock washers (H5) and two flat washers (H6).
step 1: attach bottom stretchers to one leg assembly
H4
(H6) x 2
flat washer
(H18) x 1
hex wrench
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
J
H5
H6
K
K
(H5) x 2
lock washer
7
(H4) x 2
1/4” x 15 mm bolt
K
J
The metal tabs face inward and
flush with each other
