Thrush Aircraft Inc Model S2R-T34 SECTION I
Albany, GA
AIRPLANE FLIGHT MANUAL
LIMITATIONS
FAA APPROVED: Jan. 27, 2009 Revision 4, SECTION I-5
WEIGHT AND CENTER OF GRAVITY:
NOTE
Datum is the leading edge of the wing.
Maximum Weight – 6000 pounds
C.G. Range for SINGLE & DUAL COCKPIT
* Forward Limit at 6000 pounds is 26.5 inches AFT of Datum.
* Forward Limit at 4000 pounds is 24.0 inches AFT of Datum.
* AFT Limit is 29.0 inches AFT of Datum (Normal Category).
Straight Line variation in the Forward Limit between 4000 pounds and 6000 pounds.
7,000
6,500
6,000
5,500
5,000
4,500
4,000
3,500
3,000
23.0 23.5 24.0 24.5 25.0 25.5 26.0 26.5 27.0 27.5 28.0 28.5 29.0 29.5 30.0
4,000 lbs
@ 24.0 in
6,000 lbs
@ 26.5 in
4,000 lbs
6,000 lbs
@ 29.0 in
Center of Gravity - in. aft of datum
Airplane Weight - lbs
Thrush S2R-T34 Single & Dual Cockpit
Weight & Center-of-Gravity Envelope
Normal Catagory
