INSTALLING THE JOYSTICK IN A COCKPIT OR OTHER FIXED SUPPORT
To attach the joystick in a cockpit:
- Unscrew the 4 screws located underneath the joystick’s metal base plate, and remove the
metal base plate.
- Use the 4 screw threads located on the underside of the joystick to attach the joystick
directly to your fixed support.
You can also use the 4 holes located in the corners of the metal base plates of the joystick
and the throttle to attach both elements to a fixed support.
