Thrustmaster T500RS User Manual

15/20
- Install the MOD fully and tightly into the bottom of the “Metal Stop” cavity.
- For strong resistance: position the MOD against the Upper wall.
- For even stronger resistance: position the MOD against the Lower wall.
Position against the Upper wall
(Resistance of around 14Kg/30.8lbs)
Position against the Lower wall
(Resistance of around 16Kg/35.2lbs)
- Once you have done so, tighten the “Metal Stop” (23) at the rear of the pedal arm
Position against the Upper wall Position against the Lower wall
(Resistance of around 14Kg/30.8lbs) (Resistance of around 16Kg/35.2lbs)
To avoid any calibration problems, the “Realistic Brake” MOD must only be
installed in “Long Run” position
Important note:
(do not install it in “Medium Run” or “Short Run” position)

Thrustmaster T500RS Specifications

General

Type	Racing Wheel
Force Feedback	Yes
Compatibility	PC, PlayStation 3
Rotation Angle	1080 degrees
Pedal Adjustability	Yes
Motor	Industrial-class brushless motor
Connectivity	Wired
Wheel Diameter	30 cm
Shifters	Paddle shifters
Mounting	Table
Pedals	Included (T3PA)
Power Supply	External power adapter
