Thrustmaster T500RS User Manual

18/20
- Using the 2.5mm Allen key (20) loosen the 3 "Metal Heads (17)” to turn them over 180° and
reverse the Accelerator head and the Clutch head.
You are now ready to play!
ELECTRONIC REVERSAL for the accelerator & clutch pedals
When you turn over the pedal set position: simply press the MODE button (7) to reverse the
accelerator and clutch pedals electronically
(the LED colour tells you the position you have chosen)
PEDAL SET POSITION
LED (6)
colour
ON THE FLOOR (F1 type)
(installed by default)
RED
SUSPENDED (GT/Rally type) GREEN
Once you have done this the selected position is stored immediately
in the wheel’s internal memory

Thrustmaster T500RS Specifications

General

Type	Racing Wheel
Force Feedback	Yes
Compatibility	PC, PlayStation 3
Rotation Angle	1080 degrees
Pedal Adjustability	Yes
Motor	Industrial-class brushless motor
Connectivity	Wired
Wheel Diameter	30 cm
Shifters	Paddle shifters
Mounting	Table
Pedals	Included (T3PA)
Power Supply	External power adapter
