The “CONICAL RUBBER BRAKE” mod is now installed!
Adjusting the brake pedal’s RANGE of travel and STRENGTH of
resistance
By slightly unscrewing the nut (5), you can further strengthen the resistance of the
brake pedal by moving the conical stop (2) closer to the back of the pedal’s arm (if
necessary, use a 14 mm wrench or pliers to re-tighten the nut and maintain the
selected position). The closer the conical stop is positioned to the back of the pedal’s
arm, the greater the strength of resistance wil
l be.
Note: When the conical stop is very close to the back of the brake pedal’s arm, you
may experience difficulties in reaching the maximum calibration value. Should that be
the case:
