Thule Transport T2 - Out of the Box; Tools Required for Assembly

9490-A T2 Instruction Manual
Page 2 of 12
Transport T
2
Hitch Mount Bicycle Rack
Assembl
y
& Use
To prepare your rack for installation…
Fig A-1
Fig A-2
Out of the box:
1. To prepare your rack for installation, remove the bolt, nut and washer from the rear linkage
bars using a ¾” wrench(see Fig A-1).
2. Swing the hitch base 180 degrees and line up the bushings in the middle hole with the rear
linkage bars(Fig A-2).
3. Replace the bolt, nut and washer and tighten(Fig A-2).
Tools Required for Assembly:
6mm Allen Wrench (included), ¾” wrench and a 15/16” wrench. NOTE: All fasteners are
pre-installed for easy assembly.
2. Middle hole
1. Bolt, Nut and washer to
remove
2. Rear linkage Bars
2. Hitch Base
3. Replace Bolt,
nut and washer.
