APPENDIX D WIRING TABLES AND DIAGRAMS
Table 3—Front Harness Connector Pin Assignments
PIN FUNCTION COLOR AWG
1 AUXILARY POWER RED 18
2 TURN SIGNAL, LEFT FRONT PURPLE 18
3 LOW BEAM YELLOW 18
4 HORN YELLOWw/BLACK STRIPE 18
5 TURN SIGNAL, RIGHT FRONT BROWN 18
6 HIGH BEAM WHITE 18
Table 4—Left Handlebar Connector Pin Assignments
PIN FUNCTION COLOR (pre-1996) AWG COLOR (1996-2003) AWG
1 LOW BEAM (FROM SWITCH YELLOW 18 YELLOW 18
2 HOR SWITCH POWER ORANGE 18 ORANGEw/WHITE STRIPE 18
3 DIMMER SWITCH POWER BLUE 18 BLUE 18
4 HIGH BEAM (FROM SWITCH WHITE 18 WHITE 18
5 LEFT SIGNAL POWER GREEN 18 ORANGEw/WHITE STRIPE* 18
6 BLOCK-OFF-PIN N/A N/A N/A 18
7 HORN (FROM SWITCH) BLACK 18 YELLOWw/BLACK STRIPE 18
8 BLOCK-OFF-PIN N/A N/A N/A N/A
9 FROM LEFT SIGNAL SWITCH VIOLET 18 WHITEw/PURPLE STRIPE 18
*Not required for 1996-2003 partial diagnostic method
Table 5—Right Handlebar Connector Pin Assignments
PIN FUNCTION COLOR (pre-1996) AWG COLOR (1996-2003) AWG
1 RIGHT SIGNAL SWITCH POWER GREEN 18 ORANGEw/WHITE STRIPE* 18
2 BRAKE SWITCH POWER ORANGE 18 ORANGEw/WHITE STRIPE 18
3 KILL SWITCH POWER GREY 18 GREY 18
4 GROUND (TO CHASSIS) BLACK 18 BLACK 18
5 START RELAY (FROM SWITCH) BLACK 18 BLACKw/RED STRIPE 18
6 COIL + (FROM KILL SWITCH) WHITE 18 WHITEw/BLACK STRIPE 18
7 BLOCK-OFF-PIN N/A 18 N/A N/A
8 FROM RIGHT SIGNAL SWITCH BROWN 18 WHITEw/BROWN STRIPE 18
9 BRAKE LIGHT (FROM SWITCH) RED 18 REDw/YELLOW STRIPE 18
*Not required for 1996-2003 partial diagnostic method
Table 6 – Rear Harness Connector Pin Assignments
PIN FUNCTION COLOR AWG
1 AUXILARY POWER (3A) RED 18
2 HORN YELLOWw/BLACK STRIPE 18
3 BRAKE LIGHT REDw/YELLOW STRIPE 18
4 TURN SIGNAL, RIGHT REAR BROWN 18
5 BRAKE SWITCH REDw/BLUE STRIPE 18
6 IGNITION SYSTEM (COIL +) WHITEw/BLACK STRIPE 18
7 TURN SIGNAL, LEFT REAR PURPLE 18
8 BRAKE SWITCH ORANGE 18
9 TAIL LIGHT BLUE 18
10 NEUTRAL SWITCH YELLOW 18
11 OIL SWITCH GREEN 18
12 STARTER SOLENOID GREEN 12
13 BATTERY + BLACK 12
14 IGNITION SWITCH RED 12
15 IGNITION SWITCH REDw/BLACK STRIPE 12
