12. Install the switch with the switch boot.
13.C nstall the
receiver inside the balloon, use tape or small rubber
band to seal the opening. This will help to protect
the receiver in case of flipping. Do the same way to
the battery case.
onnect all wires properly then i
14. Seal the radio box cover with mask tape as shown.
15. Refer to engine manual for fuel line connection.
Connect all fuel lines properly. Make sure there is
enough fuel line so engine pivot freely.
16.Thread the antenna through the guide tube then
insert the antenna guide tube on the radio box cover.
Use CA to secure the guide tube in place.
8
150x50x10(mm)
20. Choose and apply the desired racing no. as shown.
9
18.Thread the antenna through the canopy and
attach to the hull. The super magnet will help to
position in place perfectly.
19. Attach the rubber plug at the transom. Make sure
it is tight fit in the hole.
22. Secure the recovery pads in place with double
side tape.
21. Trim the pads as photo shown. It has to trim
away the aft portion so water will not stay in the pad.
The recovery pad is not necessary unless you run
into any Hooking situation. < One of the sponsons
digs into the water and spins suddenly the rear of
the boat around. Engine is easy killed when this
occurs. These pads are not necessary to install if
race in clam water. Test this and see if it improves
the handling under your driving conditions.
17.Use hobby knife to cut a piece of foam
(dimension LxWxH:150x50x10mm) from the
protection insert. Apply the foam inside the canopy
with furnished double side tape as indicated. This
foam works as a floating device .
