b
6
a. Install 8 AA-size alkaline batteries into transmitter.
b. Install 4 AA-size alkaline batteries into receiver battery box, and connect the battery connectors from
car and battery box (both of which are red).
c. Use the reusable zip-ties from Step 1 and secure the battery box to battery plate. Install the battery
box with plate onto the two battery posts. Secure with body clips and cut off excess zip-tie.
RADIO BATTERY INSTALLATION
3
a
b
c
a. To glue the tires, peel back the tire from wheel.
b. Place a drop of CA glue into the opening, rotate to the next area without glue, place another drop, and
keep doing this until tire and wheels are glued. Only do this step to one side of tire/wheel at a time.
c.After the CA glue has been applied, place a rubber band on the side the tire/wheel with glue until the
glue has completely dried. Then, repeat the above steps for the other side of the tire/wheel.
GLUING TIRES / WHEELS
4
a
b
c
a. Check the frequency printed on the transmitter crystal.
b. Remove the radio receiver from box with a screw driver. Check the frequency printed on the receiver
crystal, and make sure it matches with the transmitter crystal. Make sure no one will operate on the
same frequency when you are. When there is a radio glitch, it will most likely be caused by improper
crystal, damaged crystal, or people operating on the same frequency. After checking, place the receiver
back in the box and secure the receiver box top.
c. Install the antenna into transmitter.
PREPARING THE RADIO
a
c
5
