THUNDER TIGER Tomahawk User Manual

Assemble left and right side the same way
左右側組件相同
Drill holes with the specified diameter
依標示尺寸鑽孔
Pay close attention here
注意組裝步驟
Cut off shaded portion
依標示部分裁切
STEP22
STEP23
Tire/Wheels 輪胎及輪轂
Body Shell 車殼
23
Thetiresandwheelsinyourkitmayvaryfrom
thoseshowninthepictures.ThunderTigeris
constantlyworkingtoupgradeourkitsandwe
reserve the right to changespecificatioins
withoutpriornotice.
本套件所附之輪胎與輪轂可能跟圖示有所差異。
因產品後續之設計研發或功能不斷改善之原因，
我們將保留產品規格變更權利，不再另行通知使
用者。
4mm
Washer
墊圈
4x12mm
Socket Hex Machine Screw
內六角固定螺絲
4
4
2
1
Body Clip
車殼R型插銷
2
1
1
1
2
2
1
1
5.5mm
5.5mm
5.5mm
