AS6159 Wing Set
AS6023 Control Horn Set
PE0009 Hardware Set
AS6160 Pushrod Set
AS6164 Decal
IMPORTANT
Please check the contents of your kit box with these part sketches before beginning
construction. This will not only familiarize you with the parts and their names, but it
will also give you a head start in the unlikely event that you are missing a part.
Parts are not necessarily drawn actual size
AS6166 Vertical Tail
AS6158 Fuselage
AS6142 Landing Gear Set
AS6165 Horizontal Tail
Fuselage(1)
Wheel (2)
Z Bent Pushrod (2)
2mm HEX Nut (2)
Control Horn Back Plate(2)
Plastic Guide Tube (2)
Main Landing Gear (1)
3mmx5mm Screw (2)
Collar (2)
2mmx8mm Screw (4)
Pushrod Connector (2)
Allen Wrench (1)
3mmx3mm Screw (2)
(Left/1,Right/1)
Dihedral Brace (2)
Wing Protector (1)
Servo Tray (2)
Bushing (2)
JE6452
