PARTS SKETCHES
4
PARTS SKETCHES
IMPORTANT
Please check the contents of your kit box with these part sketches before beginning construction. This
will not only familiarize you with the parts and their names, but it will also give you a head start in the
unlikely event that you are missing a part. If parts are missing, call (660) 584-6704.
Parts are not necessarily drawn actual size!
Parts are not necessarily drawn actual size!
Replacement parts can be ordered by Set Number Only.
Individual parts not available.
AS6108 Wing Set
Left Wing (1) Right Wing (1)
Tape (4) Wing Joiner (2)
Silicone Tube (1) Straight Nipple (1)
Fuel Stopper (1)
75c.c Tank (1)
Cap (1)
Clunk (1)
90-degree Nipple (1)
3271 Fuel Tank Set
PE0009 Hardware Set
AS6109 Control Horn Set
AS6110 Hatch
Control Horn (2)
2mmx15mm Screw (4)
Tow Hook (1)Clevis (2)Backplate (2)
Allen Wrench (1)
Rod Connector (1)
Set Screw (1) 2mm Nut (1)
Left/Right Hatch (2) PVC Plate (2)
2mmx5mm Wood Screw (4)
2.6mmx8mm Wood Screw (3)
6/32x18 Screw (2)
AS6111 Engine Pod
3mm Nut (2)
3mmx12mm Screw (4) Spring Washer (4)
Push Rod (2)
Fuselage(1)
AS6107 Fuselage
AS6112 Vertical Fin/Tip
AS6113 Decal
2mmx8mm Wood Screw(4)
Left Fin Right Fin
Decal (1)
Engine Pod (1)
