6
SPECIFICATIONS
LED DISPLAY SCREEN OPTIONS:
1. If charging a Calcium battery push the selector button for 3 seconds
so the green Calcium LED is on.
2. Only use this function when charging a Calcium battery, using the
Calcium charge function on any other battery may cause damage.
3. If charging a GEL, AGM or standard Lead Acid battery simply connect and
forget as the charger will choose a suitable charge rate for that battery.
4. Charging voltage will display on screen at all times during the
charging process.
5. Battery capacity display will show 10% for each bar of the THUNDER logo.
When the THUNDER logo is illuminated the battery is fully charged (100%).
6. If reverse polarity connected, the orange LED on the display will flash.
7. The charger will not operate unless the charger is connected correctly.
Battery capacity: 15-150Ah and 200Ah for maintenance.
ONLY TO BE USED WITH 12V BATTERIES -
NEVER ATTEMPT TO RECHARGE DRY CELL BATTERIES.
Specifications
CHARGING VOLTAGES
GEL LEAD ACID / AGM CALCIUM
CHARGING STAGES
14.3 Volt 14.8 Volt 15.6 Volt
BOOST
14.8 Volt 15.2 Volt 16.2 Volt
FLOAT
13.3 Volt 13.7 Volt 13.7 Volt
SPECIFICATIONS
INPUT VOLTAGE
230VAC / 50HZ
TYPE
8 Stage Pulse
APPROVAL
IP65, CE, EMC, SAA and C-TICK
SAFETY PROTECTION
Over charging, reverse polarity
(Flashing LED), short circuit and
over temperature
MINIMUM START VOLTAGE
≥0V
OPERATING TEMPERATURE
-15°C - +50°C
MAXIMUM CHARGING CURRENT
8 Amps
