15
GENERAL
INPUT (NOMINAL) 240V AC, 50Hz or 110V AC 60 Hz
INPUT POWER 120W
OUTPUT VOLTAGE 12V DC
MINIMUM START VOLTAGE 10.5V
BACK DRAIN 0.1A
REVERSE POLARITY PROTECTION By fuse
BATTERY BOX DIMENSIONS
INTERNAL 180mm(W) x 330mm(L) x 238mm(H)
EXTERNAL 240mm(W) x 440mm(L) x 327mm(H)
WEIGHT 4.62kg
CHARGE CONTROL
CHARGE
Up to:
14.5V (Lead Acid)
14.1V (Gel)
14.5V (AGM)
14.9V (Calcium)
14.6V (Lithium-Ion Phosphate LiFePO4)
BOOST Constant voltage for up to 1.5 hours
RESTING Allows voltage to drop to float voltage
FLOAT 13.5V or 13.7V (LiFePO4) for 500 hours
RE-AWAKEN Return to charge cycle after 500 hours
BATTERY RANGE
DEEP CYCLE 60Ah-140Ah
AUTOMOTIVE 300-800CCA
MARINE 350-950MCA
TYPES OF BATTERIES
12V Lead Acid batteries including Gel, AGM, Wet,
Calcium and 12V Lithium-Ion Phosphate batteries
OUTPUTS
2 X CIGARETTE SOCKETS 12V 10A rated
1 X ANDERSON SOCKET 12V 50A rated
1 X 240V AC SOCKET 240V 50hz modified sine wave
2 X EXTERNAL TERMINALS 12V 100A rated
1 X USB OUTLET 5V 2.1A max
TECHNICAL INFORMATION
