Installation Specifications
*When fitting the TDR02010 to a caravan the cable will need to be connected to the towing
vehicle with a suitable heavy duty connector such as a 50A “Anderson” connector or similar.
ONLY TO BE USED WITH 12V BATTERIES, NEVER ATTEMPT TO
RECHARGE DRY CELL BATTERIES.
INSTALLATION SPECIFICATIONS
SPECIFICATIONS
CHARGING STYLE
8 stage from vehicle and 3 stage from
solar
INPUT
12.4 to 16.0 Volts DC
OUTPUT VOLTAGE
13.1-16.2V (stops charging when
alternator or vehicle battery below 11.9V)
OUTPUT CURRENT
20 Amps
MINIMUM START VOLTAGE
FOR 2ND BATTERY
1.5 Volts
MAXIMUM SOLAR INPUT VOLTAGE
25 Volts
MAXIMUM SOLAR WATT INPUT
300 Watts
SOFT START
Yes
BATTERY RANGE
18 to 250Ah
RECOMMENDED MINIMUM CABLE LENGTH / TWIN CORE
0 - 1 METRE
6mm/17AWG
1 - 5 METRE
8 B&S/8AWG
5 METRES PLUS
6 B&S/6AWG* amperage control
