5
The Thunder 60L Fridge/Freezer is powered by DC (12 and 24 Volt) or AC (240 Volt). The DC cables must have a suitable cross-section for their length
(measured from the battery to the unit), according to below:
OPERATION
Product Specifications & Operation
PRODUCT SPECIFICATIONS
SPECIFICATIONS
EXTERNAL DIMENSIONS 445 (H) x 800 (L) x 455mm (W) WEIGHT 26kg (empty)
INTERNAL DIMENSIONS - LARGE BASKET 325 (H) 390 (L) x 340mm (W) CURRENT DRAW 3.3 - 6A
INTERNAL DIMENSIONS - SMALL BASKET 140 (H) 170 (L) x 340mm (W) VOLTAGE 12/24V
CAPACITY 60L CIRCUIT PROTECTION 10A
TEMPERATURE RANGE -18° C to +10° C HIGH/LOW VOLTAGE CUT OUT 31.5/10.5V
REFRIGERANT R134a WARRANTY 3 years
RECOMMENDED MINIMUM CABLE LENGTH / TWIN CORE
0 - 2 METRES
4mm
2 - 5 METRES
6mm
5 METRES PLUS
8 B&S
