SPECIFICATIONS
Table of Contents
RATED CURRENT 30A OPERATING TEMPERATURE -10°C to 60°C
RATED VOLTAGE 12V/24V STORAGE TEMPERATURE -30°C to 70°C
OPEN CIRCUIT OF SOLAR PANEL <50V DIMENSIONS 90mm(L) x 188mm(W) x 48mm(D)
LOW VOLTAGE DISCONNECTION (LVD) 10.7V/21.4V MOUNTING HOLE SPACING 60mm x 178mm
FLOAT VOLTAGE 14V/28V WEIGHT 360g
LOW VOLTAGE RECONNECTION (LVR) 12.6V/25.2V BATTERY TYPE Wet cell rechargeable only
NO LOAD CURRENT ≤ 30ma
