Thunder TDR15008 - LCD Symbol Descriptions; Load Circuit Off; Load Circuit On (No Current); Load Circuit On (Current Drawn)

4
Components
DESCRIPTION OF LCD SYMBOLS
LCD SYMBOLS
Load circuit off No charge going to battery
Load circuit on (no current) Bulk charging battery
Load circuit on (current being drawn) Float charging battery
System is working correctly Battery running low
Battery capacity indicator Solar power active
Solar not active Load timer control on
