Thyracont VD85 - Overview

27
vd84-201113
Operation
Mode
Renew Battery
Pressure Display
Refresh: 1.0s
100 – 1.0-3 mbar
"ur": < 1.0-3mbar
Pressure Unit
Mode
Key
Cover of
Battery
Compartment
Connection f.
Mains Adapter
12…15V=, 50mA
jack 2,5mm
(+ on top)
USB Interface
Sensor Connector
2.4 Overview
