2007.03.07 Flow2 stairlift Tab 04: Install, adjust and release
www.ThyssenKruppAccessibility.nl 25
Assembly
1. Fit the rail system landing brackets with the correct mounting materials to the stairs. Drill holes
if necessary.
2. Fit the rail system tread brackets with the correct mounting materials to the stairs. Drill holes if
necessary.
3. Fit the rail system floor brackets with the correct mounting materials to the stairs. Drill holes if
necessary.
CAUTION
After fixing the rail, check that the drive unit load assembly does not touch the rail
supports. Loosen the bolt concerned and use a clamp that pushes the rail further from
the rail support. Then re-tighten the bolt.
