2007.03.07Flow2 stairliftTab 04: Install, adjust and release
www.ThyssenKruppAccessibility.nl32
Releasing the product
7. The chair’s seat is free of the landing floor/ceiling (min. 900 mm from the centre of
the chair).
8. Clearance between armrest and top/bottom is at least 80 mm (if applicable).
9. The backrest is free of the wall.
10. Boarding and alighting heights as measured from the seat: top ...... bottom ......
Footrest height set to: top ...... bottom ......
11. Safety belt is present and adjusted to the right length.
12. The rotation when the chair is moving works correctly.
13. The armrest control works correctly, and is fitted on the lower side.
14. The blue LED on the service cover is on continuously.
15. The warning tones have been set to the right level.
16. The installation number has been entered on the load sticker.
Rail
1. The rail is not damaged (paint).
2. All bolts and nuts are tight.
3. All wiring is fitted correctly, and is not pinched anywhere.
4. End stops (above and/or below) have been fitted.
5. The wiring of the charging contacts has been fitted correctly.
6. The chair unit passes smoothly over the joints in the rail.
7. The undercarriage wheels run clear of the legs.
8. The spring-loaded drive unit charging contact runs clear of the legs.
9. The rail has been greased.
Call and park units
1. The call positions have been correctly positioned.
2. The parking positions have been correctly positioned.
3. The control buttons function correctly.
4. The right joysticks are present.
Other
1. Convex mirrors (optional) have been fitted if the entire stairlift is not otherwise
visible from the C/S stations.
CE checklist Score
