Thytronic NA10 User Manual

IN39 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN39 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN40
IN40
Logic Active-ON | Active-OFF
IN40 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN40 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN40 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN41
IN41
Logic Active-ON | Active-OFF
IN41 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN41 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN41 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN42
IN42
Logic Active-ON | Active-OFF
IN42 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN42 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN42 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Relays
K1
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K2
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K3
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
