Thytronic NA10

FUNCTION CHARACTERISTICS
22
NA10 - Manual - 04 - 2022
4 FUNCTION CHARACTERISTICS4 FUNCTION CHARACTERISTICS
4.1 HARDWARE DESCRIPTION
The following figure illustrates the basic structure of the NA10 relay
Printed boards hold the circuit components arranged according to a modular allocation of the main
functions.
hw.ai
RTC
EEprom
Flash SRam
SRam
SPI
CPU
ETHERNET
CPU BOARD
POWER SUPPLY BOARD
INPUT MODULE
DSP
DUAL
PORT
1A/5A
≈
≈
≈
≈
EEprom
Thybus
RS485
RELAYS
K1...K6
Output contacts
USB
MMI
LCD
LEDs
BINARY INPUTS
IN1
Input
IN2
BLOCK I/O
BLKIN
Input
Output
BLKOUT
POWER SUPPLY
+5 V +10 V 0 V +24 V -10 V POWER FAIL RESET
Uaux
