Thytronic NA10 User Manual

Loop 1 Sign Loop1-Sign Unipolar | Bipolar
Loop 1 Nominal multiplier Loop1-M 0.01 ... 100.00 step = 0.01
Current loop 2
Loop 2 Measure assigned Loop2-Mis Frequency | IL1 | IL2 | IL3 | IE | IL | PLC | None
Loop 2 Output range Loop2-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 2 Sign Loop2-Sign Unipolar | Bipolar
Loop 2 Nominal multiplier Loop2-M 0.01 ... 100.00 step = 0.01
Current loop 3
Loop 3 Measure assigned Loop3-Mis Frequency | IL1 | IL2 | IL3 | IE | IL | PLC | None
Loop 3 Output range Loop3-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 3 Sign Loop3-Sign Unipolar | Bipolar
Loop 3 Nominal multiplier Loop3-M 0.01 ... 100.00 step = 0.01
Current loop 4
Loop 4 Measure assigned Loop4-Mis Frequency | IL1 | IL2 | IL3 | IE | IL | PLC | None
Loop 4 Output range Loop4-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 4 Sign Loop4-Sign Unipolar | Bipolar
Loop 4 Nominal multiplier Loop4-M 0.01 ... 100.00 step = 0.01
Self-test Relay
MINOR Fail alarm NO | YES
Self-test relay K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
MMI
Display modules Assigned modules | All modules
Profile selection
Active profile A | B | By INPUT
Profile A
Thermal protection with RTD thermometric probes - 26
PT1 Probe
ThAL1 Alarm
ThAL1 Enable ThAL1 Enable OFF | ON
26 PT1 Alarm threshold ThAL1 ^C 0 ... 200 step = 1
ThAL1 Operating time
Value s 0 ... 100 step = 1
ThAL1 Alarm relays ThAL1-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL1 Alarm LEDs ThAL1-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Th>1 Trip
Th>1 Enable Th>1 Enable OFF | ON
26 PT1 Trip threshold Th>1 ^C 0 ... 200 step = 1
Th>1 Operating time
Value s 0 ... 100 step = 1
Th>1 Breaker failure Th>1BF OFF | ON
Th>1 Trip relays Th>1-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>1 Trip LEDs Th>1-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
PT2 Probe
ThAL2 Alarm
ThAL2 Enable ThAL2 Enable OFF | ON
26 PT2 Alarm threshold ThAL2 ^C 0 ... 200 step = 1
ThAL2 Operating time
Value s 0 ... 100 step = 1
ThAL2 Alarm relays ThAL2-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL2 Alarm LEDs ThAL2-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Th>2 Trip
Th>2 Enable Th>2 Enable OFF | ON
26 PT2 Trip threshold Th>2 ^C 0 ... 200 step = 1
Th>2 Operating time
