I>>> Start relays I>>>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I>>> Trip relays I>>>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I>>> Start LEDs I>>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
I>>> Trip LEDs I>>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Definite time
50/51 Third threshold definite time
State OFF | ON
Pickup value In
0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 40.0 step = 0.1
I>>>def within CLP ICLP>>>def In
0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 40.0 step = 0.1
I>>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
Residual overcurrent - 50N/51N
IE> Element
Setpoints
IE> Enable IE> Enable OFF | ON
IE> Curve type IE>Curve
IEC/BS A | IEC/BS B | IEC/BS C | ANSI/IEEE MI |
ANSI/IEEE VI | ANSI/IEEE EI | EM | DEFINITE
IECLP> Mode IECLP> Mode OFF | ON - Element blocking | ON - Change setting
IECLP> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
tE> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE> Logical block IE>BLK1 OFF | ON
IE> Input selective block IE>BLK2IN OFF | ON
IE> Output selective block IE>BLK2OUT OFF | ON
IE> Second harmonic restraint IE>2ndh-REST OFF | ON
IE> Breaker failure IE>BF OFF | ON
IE> Start relays IE>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE> Trip relays IE>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE> Start LEDs IE>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
IE> Trip LEDs IE>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Definite time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>def within CLP IECLP>def IEn
0.002 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>def Operating time
Value s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
Inverse time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.010 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>inv within CLP IECLP>inv IEn
0.010 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>inv Operating time tE>inv s
0.02 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
