PRON NA60-MB0 Remote Setting Manual Page: 19 of 59
VAR REF IDX DIM TYPE Range Um Kv ENUM
Commands
Day 4x 1 1 UWORD 1,31,1 1
Month 4x 2 1 UWORD 1,12,1 1
Year 4x 3 1 UWORD 2000,2099,1 1
Hour 4x 4 1 UWORD 0,23,1 1
Minute 4x 5 1 UWORD 0,59,1 1
Second 4x 6 1 UWORD 0,59,1 1
Testing rele 4x 7 1 WORD 0="K1",1="K2",2="K3",3="K4"
,4="K5",5="K6",6="K7",7="K8
",8="K9",9="K10"
PLC2 Holding register - 1 4x 8 1 UWORD 1,65535,1 1
PLC2 Holding register - 2 4x 9 1 UWORD 1,65535,1 1
Info
Code 3x 1 6 STR
Serial number 3x 7 2 LONG 1
Application sw release - 3x 9 6 not defined
Base sw release 3x 15 6 STR
DSP fw identifier 3x 21 1 UWORD 1
DSP fw release 3x 22 6 STR
Communication
Address 3x 28 1 UBYTE 1
Remote Ethernet IP host address 3x 29 8 STR
Remote Ethernet IP Net Mask 3x 37 8 STR
Remote Ethernet Autonegotiation 1x 1 1 BIT 0=OFF, 1=ON
Enable 1x 2 1 BIT 0=OFF, 1=ON
