PRON NA60-MB0
Version 3.50
PRON NA60-MB0 Remote Setting Manual
Page: 20 of 59
VAR REF IDX DIM TYPE Range Um Kv ENUM
Rated nominal values
Relay reference name 3x 45 10 STR
Relay phase nominal current - In 3x 55 2 ULONG A 1
Relay residual nominal current - IEn 3x 57 2 ULONG A 1
Phase CT primary nominal current - Inp 3x 59 2 ULONG A 1
Residual CT primary nominal current - IEnp 3x 61 2 ULONG A 1
Relay nominal voltage ( phase to phase ) - Un 3x 63 2 ULONG V 1
Line VT primary nominal voltage ( phase to phase ) - Unp 3x 65 2 ULONG V 1
Relay residual nominal voltage ( direct measurement ) - UEn 3x 67 2 ULONG V 1
Residual primary nominal voltage ( phase to phase ) * 1.73 -
UEnp
3x 69 2 ULONG V 1
Relay nominal frequency - fn 3x 71 2 ULONG Hz 1
Measurements reading mode 3x 73 1 WORD 0="RELATIVE",1="PRIMARY
"
Profile selection
Profile 3x 74 1 WORD 0="A",1="B"
Clock
Day 3x 75 1 UWORD 1
Month 3x 76 1 UWORD 1
Year 3x 77 1 UWORD 1
Hour 3x 78 1 UWORD 1
Minute 3x 79 1 UWORD 1
Second 3x 80 1 UWORD 1
