APPENDIX
136
NG10 - Manual - 04 - 2022
IN2 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | H-L-87GML Block1 |
H Block1 | L Block1 | 87GML Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Relays
K1
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K2
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K3
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K4
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K5
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K6
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
LEDs
START
Type No-latched | Latched
TRIP
Type No-latched | Latched
L1
Type No-latched | Latched
L2
Type No-latched | Latched
L3
Type No-latched | Latched
L4
Type No-latched | Latched
L5
Type No-latched | Latched
L6
Type No-latched | Latched
Analog outputs
Current loop 1
Loop 1 Measure assigned Loop1-Mis
Frequency | IL1H | IL2H | IL3H | IE | IEH | IESH | ILH |
IL1L | IL2L | IL3L | ILL | ISL1 | ISL2 | ISL3 | IDL1 | IDL2
| IDL3 | PLC | None
Loop 1 Output range Loop1-Range 0-5 mA | 0-20 mA | 4-20 mA
Loop 1 Output type Loop1-Type Unipolar | Bipolar
