Loop 1 Nominal multiplier Loop1-M 0.01 ... 100.00 step = 0.01
Loop 1 Terminals polarity Loop1-Polarity Normal | Reverse
Current loop 2
Loop 2 Measure assigned Loop2-Mis
Frequency | IL1H | IL2H | IL3H | IE | IEH | IESH | ILH |
IL1L | IL2L | IL3L | ILL | ISL1 | ISL2 | ISL3 | IDL1 | IDL2
| IDL3 | PLC | None
Loop 2 Output range Loop2-Range 0-5 mA | 0-20 mA | 4-20 mA
Loop 2 Output type Loop2-Type Unipolar | Bipolar
Loop 2 Nominal multiplier Loop2-M 0.01 ... 100.00 step = 0.01
Loop 2 Terminals polarity Loop2-Polarity Normal | Reverse
Current loop 3
Loop 3 Measure assigned Loop3-Mis
Frequency | IL1H | IL2H | IL3H | IE | IEH | IESH | ILH |
IL1L | IL2L | IL3L | ILL | ISL1 | ISL2 | ISL3 | IDL1 | IDL2
| IDL3 | PLC | None
Loop 3 Output range Loop3-Range 0-5 mA | 0-20 mA | 4-20 mA
Loop 3 Output type Loop3-Type Unipolar | Bipolar
Loop 3 Nominal multiplier Loop3-M 0.01 ... 100.00 step = 0.01
Loop 3 Terminals polarity Loop3-Polarity Normal | Reverse
Current loop 4
Loop 4 Measure assigned Loop4-Mis
Frequency | IL1H | IL2H | IL3H | IE | IEH | IESH | ILH |
IL1L | IL2L | IL3L | ILL | ISL1 | ISL2 | ISL3 | IDL1 | IDL2
| IDL3 | PLC | None
Loop 4 Output range Loop4-Range 0-5 mA | 0-20 mA | 4-20 mA
Loop 4 Output type Loop4-Type Unipolar | Bipolar
Loop 4 Nominal multiplier Loop4-M 0.01 ... 100.00 step = 0.01
Loop 4 Terminals polarity Loop4-Polarity Normal | Reverse
Self-test Relay
MINOR Fail alarm NO | YES
Self-test relay K1 | K2 | K3 | K4 | K5 | K6
MMI
Display modules Assigned modules | All modules
Profile selection
Active profile A | B | By INPUT
Profile A
Thermal protection with RTD thermometric probes - 26
PT1 Probe
ThAL1 Alarm
ThAL1 Enable ThAL1 Enable OFF | ON
26 PT1 Alarm threshold ThAL1 ^C 0 ... 200 step = 1
ThAL1 Operating time
Value s 0 ... 100 step = 1
ThAL1 Alarm relays ThAL1-K K1 | K2 | K3 | K4 | K5 | K6
ThAL1 Alarm LEDs ThAL1-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>1 Trip
Th>1 Enable Th>1 Enable OFF | ON
26 PT1 Trip threshold Th>1 ^C 0 ... 200 step = 1
Th>1 Operating time
Value s 0 ... 100 step = 1
Th>1 Breaker failure Th>1BF OFF | ON
Th>1 Trip relays Th>1-K K1 | K2 | K3 | K4 | K5 | K6
Th>1 Trip LEDs Th>1-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT2 Probe
ThAL2 Alarm
ThAL2 Enable ThAL2 Enable OFF | ON
26 PT2 Alarm threshold ThAL2 ^C 0 ... 200 step = 1
To Next Page
