APPENDIX
138
NG10 - Manual - 04 - 2022
ThAL2 Operating time
Value s 0 ... 100 step = 1
ThAL2 Alarm relays ThAL2-K K1 | K2 | K3 | K4 | K5 | K6
ThAL2 Alarm LEDs ThAL2-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>2 Trip
Th>2 Enable Th>2 Enable OFF | ON
26 PT2 Trip threshold Th>2 ^C 0 ... 200 step = 1
Th>2 Operating time
Value s 0 ... 100 step = 1
Th>2 Breaker failure Th>2BF OFF | ON
Th>2 Trip relays Th>2-K K1 | K2 | K3 | K4 | K5 | K6
Th>2 Trip LEDs Th>2-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT3 Probe
ThAL3 Alarm
ThAL3 Enable ThAL3 Enable OFF | ON
26 PT3 Alarm threshold ThAL3 ^C 0 ... 200 step = 1
ThAL3 Operating time
Value s 0 ... 100 step = 1
ThAL3 Alarm relays ThAL3-K K1 | K2 | K3 | K4 | K5 | K6
ThAL3 Alarm LEDs ThAL3-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>3 Trip
Th>3 Enable Th>3 Enable OFF | ON
26 PT3 Trip threshold Th>3 ^C 0 ... 200 step = 1
Th>3 Operating time
Value s 0 ... 100 step = 1
Th>3 Breaker failure Th>3BF OFF | ON
Th>3 Trip relays Th>3-K K1 | K2 | K3 | K4 | K5 | K6
Th>3 Trip LEDs Th>3-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT4 Probe
ThAL4 Alarm
ThAL4 Enable ThAL4 Enable OFF | ON
26 PT4 Alarm threshold ThAL4 ^C 0 ... 200 step = 1
ThAL4 Operating time
Value s 0 ... 100 step = 1
ThAL4 Alarm relays ThAL4-K K1 | K2 | K3 | K4 | K5 | K6
ThAL4 Alarm LEDs ThAL4-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>4 Trip
Th>4 Enable Th>4 Enable OFF | ON
26 PT4 Trip threshold Th>4 ^C 0 ... 200 step = 1
Th>4 Operating time
Value s 0 ... 100 step = 1
Th>4 Breaker failure Th>4BF OFF | ON
Th>4 Trip relays Th>4-K K1 | K2 | K3 | K4 | K5 | K6
Th>4 Trip LEDs Th>4-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT5 Probe
ThAL5 Alarm
ThAL5 Enable ThAL5 Enable OFF | ON
26 PT5 Alarm threshold ThAL5 ^C 0 ... 200 step = 1
ThAL5 Operating time
Value s 0 ... 100 step = 1
ThAL5 Alarm relays ThAL5-K K1 | K2 | K3 | K4 | K5 | K6
ThAL5 Alarm LEDs ThAL5-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>5 Trip
Th>5 Enable Th>5 Enable OFF | ON
