Thytronic NG10 User Manual

APPENDIX
139
NG10 - Manual - 04 - 2022
26 PT5 Trip threshold Th>5 ^C 0 ... 200 step = 1
Th>5 Operating time
Value s 0 ... 100 step = 1
Th>5 Breaker failure Th>5BF OFF | ON
Th>5 Trip relays Th>5-K K1 | K2 | K3 | K4 | K5 | K6
Th>5 Trip LEDs Th>5-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT6 Probe
ThAL6 Alarm
ThAL6 Enable ThAL6 Enable OFF | ON
26 PT6 Alarm threshold ThAL6 ^C 0 ... 200 step = 1
ThAL6 Operating time
Value s 0 ... 100 step = 1
ThAL6 Alarm relays ThAL6-K K1 | K2 | K3 | K4 | K5 | K6
ThAL6 Alarm LEDs ThAL6-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>6 Trip
Th>6 Enable Th>6 Enable OFF | ON
26 PT6 Trip threshold Th>6 ^C 0 ... 200 step = 1
Th>6 Operating time
Value s 0 ... 100 step = 1
Th>6 Breaker failure Th>6BF OFF | ON
Th>6 Trip relays Th>6-K K1 | K2 | K3 | K4 | K5 | K6
Th>6 Trip LEDs Th>6-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT7 Probe
ThAL7 Alarm
ThAL7 Enable ThAL7 Enable OFF | ON
26 PT7 Alarm threshold ThAL7 ^C 0 ... 200 step = 1
ThAL7 Operating time
Value s 0 ... 100 step = 1
ThAL7 Alarm relays ThAL7-K K1 | K2 | K3 | K4 | K5 | K6
ThAL7 Alarm LEDs ThAL7-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>7 Trip
Th>7 Enable Th>7 Enable OFF | ON
26 PT7 Trip threshold Th>7 ^C 0 ... 200 step = 1
Th>7 Operating time
Value s 0 ... 100 step = 1
Th>7 Breaker failure Th>7BF OFF | ON
Th>7 Trip relays Th>7-K K1 | K2 | K3 | K4 | K5 | K6
Th>7 Trip LEDs Th>7-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT8 Probe
ThAL8 Alarm
ThAL8 Enable ThAL8 Enable OFF | ON
26 PT8 Alarm threshold ThAL8 ^C 0 ... 200 step = 1
ThAL8 Operating time
Value s 0 ... 100 step = 1
ThAL8 Alarm relays ThAL8-K K1 | K2 | K3 | K4 | K5 | K6
ThAL8 Alarm LEDs ThAL8-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>8 Trip
Th>8 Enable Th>8 Enable OFF | ON
26 PT8 Trip threshold Th>8 ^C 0 ... 200 step = 1
Th>8 Operating time
Value s 0 ... 100 step = 1
Th>8 Breaker failure Th>8BF OFF | ON
Th>8 Trip relays Th>8-K K1 | K2 | K3 | K4 | K5 | K6
Th>8 Trip LEDs Th>8-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
