APPENDIX
140
NG10 - Manual - 04 - 2022
Diagnostic
PT100 probe diagnostic relays PT100Diag-K K1 | K2 | K3 | K4 | K5 | K6
PT100 probe diagnostic LEDs PT100Diag-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Residual overcurrent or high impedence differential restricted ground fault - 50N/51N-87NHIZ
IE> Element
Setpoints
IE> Enable IE> Enable OFF | ON
IE> Curve type IE>Curve
IEC/BS A | IEC/BS B | IEC/BS C | ANSI/IEEE MI |
ANSI/IEEE VI | ANSI/IEEE EI | EM | DEFINITE
tE> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE> Logical block IE>BLK1 OFF | ON
IE> Input selective block IE>BLK2IN OFF | ON
IE> Output selective block IE>BLK2OUT OFF | ON
IE> Breaker failure IE>BF OFF | ON
IE> Start relays IE>ST-K K1 | K2 | K3 | K4 | K5 | K6
IE> Trip relays IE>TR-K K1 | K2 | K3 | K4 | K5 | K6
IE> Start LEDs IE>ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
IE> Trip LEDs IE>TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Definite time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>def Operating time
Value s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
Inverse time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>inv Operating time tE>inv s
0.02 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
IE>> Element
Setpoints
IE>> Enable IE>> Enable OFF | ON
tE>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>> Logical block IE>>BLK1 OFF | ON
IE>> Input selective block IE>>BLK2IN OFF | ON
IE>> Output selective block IE>>BLK2OUT OFF | ON
IE>> Breaker failure IE>>BF OFF | ON
IE> Disabling by IE>> start IE>disbyIE>> OFF | ON
IE>> Start relays IE>>ST-K K1 | K2 | K3 | K4 | K5 | K6
IE>> Trip relays IE>>TR-K K1 | K2 | K3 | K4 | K5 | K6
IE>> Start LEDs IE>>ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
IE>> Trip LEDs IE>>TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Definite time
50N/51N Second threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
