APPENDIX
141
NG10 - Manual - 04 - 2022
IE>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
IE>>> Element
Setpoints
IE>>> Enable IE>>> Enable OFF | ON
tE>>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>>> Logical block IE>>>BLK1 OFF | ON
IE>>> Input selective block IE>>>BLK2IN OFF | ON
IE>>> Output selective block IE>>>BLK2OUT OFF | ON
IE>>> Breaker failure IE>>>BF OFF | ON
IE> Disabling by IE>>> start IE>disbyIE>>> OFF | ON
IE>> Disabling by IE>>> start IE>>disbyIE>>> OFF | ON
IE>>> Start relays IE>>>ST-K K1 | K2 | K3 | K4 | K5 | K6
IE>>> Trip relays IE>>>TR-K K1 | K2 | K3 | K4 | K5 | K6
IE>>> Start LEDs IE>>>ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
IE>>> Trip LEDs IE>>>TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Definite time
50N/51N Third threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
Low impedence restricted ground fault - 64REF
64REF Enable 64REF Enable OFF | ON
64REF Minimum threshold IREF> IEn 0.05 ... 2.00 step = 0.01
64REF Intentional delay
Value s 0.03 ... 60.00 step = 0.01
64REF Logical block 64REF-BLK1 OFF | ON
64REF Output selective block 64REF-BLK2OUT OFF | ON
64REF Breaker failure 64REF-BF OFF | ON
64REF Start relays 64REF-ST-K K1 | K2 | K3 | K4 | K5 | K6
64REF Trip relays 64REF-TR-K K1 | K2 | K3 | K4 | K5 | K6
64REF Start LEDs 64REF-ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
64REF Trip LEDs 64REF-TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Differential - 87G-M-L
Common configuration
87G-M-L Enable 87G-M-L Enable OFF | ON
87G-M-L Logical block 87G-M-L BLK1 OFF | ON
87G-M-L Output selective block
87G-M-L
BLK2OUT
OFF | ON
87G-M-L Breker failure 87G-M-L BF OFF | ON
CT saturation detector
87G-M-L Saturation detector enable SatDet OFF | ON
87G-M-L Saturation detector intentional reset time delay tSatDet-RES s 0.00 ... 0.50 step = 0.01
SatDet Start relays STSatDet-K K1 | K2 | K3 | K4 | K5 | K6
SatDet Start LEDs STSatDet-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Id> Element
Setpoints
Id> Start relays Id>-ST-K K1 | K2 | K3 | K4 | K5 | K6
Id> Trip relays Id>-TR-K K1 | K2 | K3 | K4 | K5 | K6
Id> Start LEDs Id>-ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
