APPENDIX
143
NG10 - Manual - 04 - 2022
BF Logical block BF-BLK1 OFF | ON
BF Start from circuit breaker CB Input OFF | ON
BF Start relays BF-ST-K K1 | K2 | K3 | K4 | K5 | K6
BF Trip relays BF-TR-K K1 | K2 | K3 | K4 | K5 | K6
BF Start LEDs BF-ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
BF Trip LEDs BF-TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Profile B
Thermal protection with RTD thermometric probes - 26
PT1 Probe
ThAL1 Alarm
ThAL1 Enable ThAL1 Enable OFF | ON
26 PT1 Alarm threshold ThAL1 ^C 0 ... 200 step = 1
ThAL1 Operating time
Value s 0 ... 100 step = 1
ThAL1 Alarm relays ThAL1-K K1 | K2 | K3 | K4 | K5 | K6
ThAL1 Alarm LEDs ThAL1-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>1 Trip
Th>1 Enable Th>1 Enable OFF | ON
26 PT1 Trip threshold Th>1 ^C 0 ... 200 step = 1
Th>1 Operating time
Value s 0 ... 100 step = 1
Th>1 Breaker failure Th>1BF OFF | ON
Th>1 Trip relays Th>1-K K1 | K2 | K3 | K4 | K5 | K6
Th>1 Trip LEDs Th>1-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT2 Probe
ThAL2 Alarm
ThAL2 Enable ThAL2 Enable OFF | ON
26 PT2 Alarm threshold ThAL2 ^C 0 ... 200 step = 1
ThAL2 Operating time
Value s 0 ... 100 step = 1
ThAL2 Alarm relays ThAL2-K K1 | K2 | K3 | K4 | K5 | K6
ThAL2 Alarm LEDs ThAL2-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>2 Trip
Th>2 Enable Th>2 Enable OFF | ON
26 PT2 Trip threshold Th>2 ^C 0 ... 200 step = 1
Th>2 Operating time
Value s 0 ... 100 step = 1
Th>2 Breaker failure Th>2BF OFF | ON
Th>2 Trip relays Th>2-K K1 | K2 | K3 | K4 | K5 | K6
Th>2 Trip LEDs Th>2-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT3 Probe
ThAL3 Alarm
ThAL3 Enable ThAL3 Enable OFF | ON
26 PT3 Alarm threshold ThAL3 ^C 0 ... 200 step = 1
ThAL3 Operating time
Value s 0 ... 100 step = 1
ThAL3 Alarm relays ThAL3-K K1 | K2 | K3 | K4 | K5 | K6
ThAL3 Alarm LEDs ThAL3-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>3 Trip
Th>3 Enable Th>3 Enable OFF | ON
26 PT3 Trip threshold Th>3 ^C 0 ... 200 step = 1
Th>3 Operating time
Value s 0 ... 100 step = 1
Th>3 Breaker failure Th>3BF OFF | ON
