APPENDIX
144
NG10 - Manual - 04 - 2022
Th>3 Trip relays Th>3-K K1 | K2 | K3 | K4 | K5 | K6
Th>3 Trip LEDs Th>3-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT4 Probe
ThAL4 Alarm
ThAL4 Enable ThAL4 Enable OFF | ON
26 PT4 Alarm threshold ThAL4 ^C 0 ... 200 step = 1
ThAL4 Operating time
Value s 0 ... 100 step = 1
ThAL4 Alarm relays ThAL4-K K1 | K2 | K3 | K4 | K5 | K6
ThAL4 Alarm LEDs ThAL4-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>4 Trip
Th>4 Enable Th>4 Enable OFF | ON
26 PT4 Trip threshold Th>4 ^C 0 ... 200 step = 1
Th>4 Operating time
Value s 0 ... 100 step = 1
Th>4 Breaker failure Th>4BF OFF | ON
Th>4 Trip relays Th>4-K K1 | K2 | K3 | K4 | K5 | K6
Th>4 Trip LEDs Th>4-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT5 Probe
ThAL5 Alarm
ThAL5 Enable ThAL5 Enable OFF | ON
26 PT5 Alarm threshold ThAL5 ^C 0 ... 200 step = 1
ThAL5 Operating time
Value s 0 ... 100 step = 1
ThAL5 Alarm relays ThAL5-K K1 | K2 | K3 | K4 | K5 | K6
ThAL5 Alarm LEDs ThAL5-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>5 Trip
Th>5 Enable Th>5 Enable OFF | ON
26 PT5 Trip threshold Th>5 ^C 0 ... 200 step = 1
Th>5 Operating time
Value s 0 ... 100 step = 1
Th>5 Breaker failure Th>5BF OFF | ON
Th>5 Trip relays Th>5-K K1 | K2 | K3 | K4 | K5 | K6
Th>5 Trip LEDs Th>5-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT6 Probe
ThAL6 Alarm
ThAL6 Enable ThAL6 Enable OFF | ON
26 PT6 Alarm threshold ThAL6 ^C 0 ... 200 step = 1
ThAL6 Operating time
Value s 0 ... 100 step = 1
ThAL6 Alarm relays ThAL6-K K1 | K2 | K3 | K4 | K5 | K6
ThAL6 Alarm LEDs ThAL6-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>6 Trip
Th>6 Enable Th>6 Enable OFF | ON
26 PT6 Trip threshold Th>6 ^C 0 ... 200 step = 1
Th>6 Operating time
Value s 0 ... 100 step = 1
Th>6 Breaker failure Th>6BF OFF | ON
Th>6 Trip relays Th>6-K K1 | K2 | K3 | K4 | K5 | K6
Th>6 Trip LEDs Th>6-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT7 Probe
ThAL7 Alarm
ThAL7 Enable ThAL7 Enable OFF | ON
26 PT7 Alarm threshold ThAL7 ^C 0 ... 200 step = 1
