APPENDIX
145
NG10 - Manual - 04 - 2022
ThAL7 Operating time
Value s 0 ... 100 step = 1
ThAL7 Alarm relays ThAL7-K K1 | K2 | K3 | K4 | K5 | K6
ThAL7 Alarm LEDs ThAL7-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>7 Trip
Th>7 Enable Th>7 Enable OFF | ON
26 PT7 Trip threshold Th>7 ^C 0 ... 200 step = 1
Th>7 Operating time
Value s 0 ... 100 step = 1
Th>7 Breaker failure Th>7BF OFF | ON
Th>7 Trip relays Th>7-K K1 | K2 | K3 | K4 | K5 | K6
Th>7 Trip LEDs Th>7-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PT8 Probe
ThAL8 Alarm
ThAL8 Enable ThAL8 Enable OFF | ON
26 PT8 Alarm threshold ThAL8 ^C 0 ... 200 step = 1
ThAL8 Operating time
Value s 0 ... 100 step = 1
ThAL8 Alarm relays ThAL8-K K1 | K2 | K3 | K4 | K5 | K6
ThAL8 Alarm LEDs ThAL8-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Th>8 Trip
Th>8 Enable Th>8 Enable OFF | ON
26 PT8 Trip threshold Th>8 ^C 0 ... 200 step = 1
Th>8 Operating time
Value s 0 ... 100 step = 1
Th>8 Breaker failure Th>8BF OFF | ON
Th>8 Trip relays Th>8-K K1 | K2 | K3 | K4 | K5 | K6
Th>8 Trip LEDs Th>8-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Diagnostic
PT100 probe diagnostic relays PT100Diag-K K1 | K2 | K3 | K4 | K5 | K6
PT100 probe diagnostic LEDs PT100Diag-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Residual overcurrent or high impedence differential restricted ground fault - 50N/51N-87NHIZ
IE> Element
Setpoints
IE> Enable IE> Enable OFF | ON
IE> Curve type IE>Curve
IEC/BS A | IEC/BS B | IEC/BS C | ANSI/IEEE MI |
ANSI/IEEE VI | ANSI/IEEE EI | EM | DEFINITE
tE> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE> Logical block IE>BLK1 OFF | ON
IE> Input selective block IE>BLK2IN OFF | ON
IE> Output selective block IE>BLK2OUT OFF | ON
IE> Breaker failure IE>BF OFF | ON
IE> Start relays IE>ST-K K1 | K2 | K3 | K4 | K5 | K6
IE> Trip relays IE>TR-K K1 | K2 | K3 | K4 | K5 | K6
IE> Start LEDs IE>ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
IE> Trip LEDs IE>TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Definite time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>def Operating time
