APPENDIX
146
NG10 - Manual - 04 - 2022
Value s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
Inverse time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>inv Operating time tE>inv s
0.02 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
IE>> Element
Setpoints
IE>> Enable IE>> Enable OFF | ON
tE>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>> Logical block IE>>BLK1 OFF | ON
IE>> Input selective block IE>>BLK2IN OFF | ON
IE>> Output selective block IE>>BLK2OUT OFF | ON
IE>> Breaker failure IE>>BF OFF | ON
IE> Disabling by IE>> start IE>disbyIE>> OFF | ON
IE>> Start relays IE>>ST-K K1 | K2 | K3 | K4 | K5 | K6
IE>> Trip relays IE>>TR-K K1 | K2 | K3 | K4 | K5 | K6
IE>> Start LEDs IE>>ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
IE>> Trip LEDs IE>>TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Definite time
50N/51N Second threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
IE>>> Element
Setpoints
IE>>> Enable IE>>> Enable OFF | ON
tE>>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>>> Logical block IE>>>BLK1 OFF | ON
IE>>> Input selective block IE>>>BLK2IN OFF | ON
IE>>> Output selective block IE>>>BLK2OUT OFF | ON
IE>>> Breaker failure IE>>>BF OFF | ON
IE> Disabling by IE>>> start IE>disbyIE>>> OFF | ON
IE>> Disabling by IE>>> start IE>>disbyIE>>> OFF | ON
IE>>> Start relays IE>>>ST-K K1 | K2 | K3 | K4 | K5 | K6
IE>>> Trip relays IE>>>TR-K K1 | K2 | K3 | K4 | K5 | K6
IE>>> Start LEDs IE>>>ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
IE>>> Trip LEDs IE>>>TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Definite time
50N/51N Third threshold definite time
State OFF | ON
Pickup value IEn
0.005 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
Low impedence restricted ground fault - 64REF
