APPENDIX
150
NG10 - Manual - 04 - 2022
Timer 5 s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 6 s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 7 s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 8 s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 9 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 10 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 11 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 12 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 13 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 14 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 15 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 16 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 17 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 18 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 19 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 20 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 21 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 22 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 23 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 24 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Circuit Breaker supervision
LEDs-relays allocation
Open CB command relays CBopen-K K1 | K2 | K3 | K4 | K5 | K6
Close CB command relays CBclose-K K1 | K2 | K3 | K4 | K5 | K6
CB Closed LEDs CBclose-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
CB Open LEDs CBopen-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
