Thytronic NG10 User Manual

APPENDIX
151
NG10 - Manual - 04 - 2022
CB State diagnostic relays CBdiag-K K1 | K2 | K3 | K4 | K5 | K6
CB Diagnostic
Number of CB trips mode ModeN.Open OFF | ON
Number of CB trips threshold N.Open 0 ... 10000 step = 1
Cumulative CB tripping currents mode ModeSumI OFF | ON
Cumulative CB tripping currents threshold SumI InH 0 ... 5000 step = 1
Cumulative CB tripping I^2t mode ModeSumI^2t OFF | ON
Circuit breaker opening time for I^2t calculation tbreak s 0.05 ... 1.00 step = 0.01
Cumulative CB tripping I^2t threshold SumI^2t InH^2t 0 ... 5000 step = 1
CB operating time mode Mode-tOpen OFF | ON
Trigger relay for CB opening time trigger measurement Ktrig-break K1 | K2 | K3 | K4 | K5 | K6
Circuit breaker maximum allowed opening time
Value s 0.05 ... 1.00 step = 0.01
Number of CB trips diagnostic relays N.Open-K K1 | K2 | K3 | K4 | K5 | K6
Cumulative CB tripping currents diagnostic relays SumI-K K1 | K2 | K3 | K4 | K5 | K6
Cumulative CB tripping I^2t diagnostic relays SumI^2t-K K1 | K2 | K3 | K4 | K5 | K6
Circuit breaker opening time diagnostic relays tbreak-K K1 | K2 | K3 | K4 | K5 | K6
Number of CB trips diagnostic LEDs N.Open-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Cumulative CB tripping currents diagnostic LEDs SumI-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Cumulative CB tripping I^2t diagnostic LEDs SumI^2t-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Circuit breaker opening time diagnostic LEDs tbreak-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
CT supervision - 74CT
CT supervision side H - 74CT side H
74CT(H) Enable 74CT(H) Enable OFF | ON
74CT(H) Threshold S(H)< 0.10 ... 0.95 step = 0.01
74CT(H) Overcurrent threshold
State OFF | ON
Pickup value InH 0.10 ... 1.00 step = 0.01
S(H)< Operating time
Value s
0.03 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
S(H)< Logical block S(H)<BLK1 OFF | ON
S(H)< Trip relays S(H)<TR-K K1 | K2 | K3 | K4 | K5 | K6
S(H)< Trip LEDs S(H)<TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
CT supervision side L - 74CT side L
74CT(L) Enable 74CT(L) Enable OFF | ON
74CT(L) Threshold S(L)< 0.10 ... 0.95 step = 0.01
74CT(L) Overcurrent threshold
State OFF | ON
Pickup value InL 0.10 ... 1.00 step = 0.01
S(L)< Operating time
Value s
0.03 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
S(L)< Logical block S(L)<BLK1 OFF | ON
S(L)< Trip relays S(L)<TR-K K1 | K2 | K3 | K4 | K5 | K6
S(L)< Trip LEDs S(L)<TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Remote tripping
Remote tripping relays RemTrip-K K1 | K2 | K3 | K4 | K5 | K6
Remote tripping LEDs RemTrip-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Pilot wire diagnostic
BLOUT1 Diagnostic pulses period PulseBLOUT1 OFF | 100ms | 1s | 5s | 10s | 60s | 120s
BLIN1 Diagnostic pulses control time interval PulseBLIN1 OFF | 100ms | 1s | 5s | 10s | 60s | 120s
